An example setup showing the following;
Computer <-USB-> Lynx Dongle Lynx Dongle <-DMX over Cat5-> Lynx Express (TX/rx) Lynx Express (TX/rx)<- Wireless DMX Universe -> "Wireless DMX Receivers"
Example also shows how a standalone Lynx Express (tx/RX) can connect to a Lynx Express and a Lynx SSR4+DMX.
Example also shows that an SSR4+DMX can be daisy chained in a wired fashion.
Lastly example shows how a Lynx Express can have an Express Receiver daughter card installed to enable it to receive wireless DMX signals directly.
